From basic liquid immersion heaters to highly engineered turnkey process heating systems, these Process Heaters are designed to fit your manufacturing process.
Browse through our products below or Contact Us to discuss your project.
Flanged Immersion Heaters
Flanged Immersion Heaters are constructed to be easily and economically engineered into new equipment. This design consists of tubular heating elements silver brazed or TIG welded to a flange cut from steel or stainless steel plate. Flange plate size, thickness and shape are determined by the application. A fiber gasket is supplied with each heater.
Screw Plug Immersion Heaters
Screw Plug Immersion Heaters consist of tubular elements welded or brazed into a threaded screw plug which can then be inserted into a threaded opening in a tank wall or through a mating full or half coupling. Stainless Steel, Brass or Steel Screw Plugs in Four Standard Screw Plug Sizes—1″, 1-1/4″, 2″, 2-1/2″ can have an integral thermostat making them suitable for many applications.
Selecting the Proper Screw Plug Heater – PDF
Circulation Heaters
Circulation Heaters are self-contained heating units designed for optimum operating efficiency and performance. Non-pressurized or highly pressurized fluids can be heated very effectively using either direct or indirect circulation heating. All of the heat generated by the elements is immediately transferred to the medium being processed with minimal losses.
Selecting the Proper Circulation Heater – PDF
Duct Heaters
Process Air Duct Heaters are used for tempering forced air in many industrial processes. Heater wattage is dependent on air outlet temperature (up to 1200°F [650°C]) and air velocity. Forced air duct heaters can be designed specifically for high pressure and/or hazardous locations.
Turnkey systems including the duct heater, power and temperature control panel, and the temperature and over-temperature sensors can also be provided.
Enclosure Heaters
Enclosure Heaters are designed to help electric, electronic, pneumatic, hydraulic and mechanical equipment perform at top capacity by protecting them against low temperatures, condensation and corrosion. Enclosure Heaters come in four different styles of heaters:
- Ceramic Heater Enclosure Heaters
- Finned Strip Enclosure Heaters
- Silicone Rubber Enclosure Heaters
- Tubular Heater Enclosure Heaters
Other Process Heaters
- Over The Side Immersion Heaters
- Chemical Bath Immersion Heaters
- Drum Heaters
- In Line Forced Air Heaters
